Oracle X7-2 Service Manual

Identifying the Server Ports
This section describes the pinouts of the server connectors:
■
“Gigabit Ethernet Ports” on page 217
■
“Network Management Port” on page 219
■
“Serial Management Port” on page 220
■
“USB Ports” on page 221
Gigabit Ethernet Ports
The server has five auto-negotiating gigabit Ethernet (GbE) ports. Three Ethernet ports use
standard RJ-45 connectors, and two use enhanced small form-factor pluggable (SFP+) port
connectors. The transfer rates are shown in the following table.
TABLE 2
Ethernet Port Transfer Rates
Connection Type IEEE Terminology Transfer Rate
Fast Ethernet 100BASE-TX 100 Mbps
Gigabit Ethernet 1000BASE-T 1,000 Mbps
10 Gigabit Ethernet 10GBASE-T 10,000 Mbps
10/25 Gigabit Ethernet (SFP+) 10/25GbE 10,000/25,000 Mbps
RJ-45 10GbE Ports
The following figure and table describe the RJ-45 10GbE port pin signals.
Identifying the Server Ports 217

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
