Oracle X7-2 Service Manual

Power On an NVMe Storage Drive and Attach a Device Driver
Note - After you physically remove an NVMe storage drive from the server, wait at least 10
seconds before installing a replacement drive.
1.
Remove the replacement drive from its packaging and place the drive on an
antistatic mat.
2.
If necessary, remove the drive filler panel.
3.
Align the replacement drive with the drive slot.
The drive is physically addressed according to the slot in which it is installed. It is important to
install a replacement drive in the same slot as the drive that was removed.
4.
Slide the drive into the slot until the drive is fully seated.
See “Install a Storage Drive” on page 70.
5.
Close the drive latch to lock the drive in place.
See “Install a Storage Drive” on page 70.
Power On an NVMe Storage Drive and Attach a
Device Driver
1.
Type: # hotplug enable Slot100
2.
Type: # hotplug list –lc
The following status is displayed for the NVMe storage drive.
# hotplug list –lc
Connection State Description Path
---------------------------------------------------------------------------------------
Slot100 Enabled PCIe-Native /pci@13,0/pci8086,2030@0/pci111d,80b5@0/pci111d,80b5@5
3.
To check the NVMe drive health, firmware level, temperature, get error log,
SMART data, security erase, low level format, and other data, type:
# nvmeadm list
Related Information
■
“Storage Drive Status Indicators” on page 31
Servicing Storage Drives (CRU) 73

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
