Troubleshoot Hardware Faults Using the Oracle ILOM Web Interface
Note - The green System OK LED indicator and the green SP OK indicator remain lit (no
blinking) when the server is in a normal operating state.
Server System-Level Status Indicators
There are seven system-level status indicators (LEDs), some of which are located on both the
server front panel and the back panel. The following table describes these indicators.
Status Indicator
Name
Icon Color State and Meaning
Locate Button/
LED
White Indicates the location of the server.
■ OFF – Server is operating normally.
■ FAST BLINK – Use Oracle ILOM to activate this
LED indicator to enable you to locate a particular
system quickly and easily.
■ Pressing the Locate button toggles the LED indicator
fast blink on or off.
Fault-Service
Required
Amber Indicates the fault state of the server.
■ OFF – The server is operating normally.
■ STEADY ON – A fault is present on the server. This
LED indicator lights whenever a fault indicator lights
for a replaceable component on the server.
Note - When this LED indicator is lit, a system console
message might appear that includes a recommended
service action.
System OK Green Indicates the operational state of the chassis.
■ OFF – AC power is not present or the Oracle ILOM
boot is not complete.
■ STANDBY BLINK – Standby power is on, but the
chassis power is off and the Oracle ILOM SP is
running.
■ SLOW BLINK – Startup sequence was initiated on
the host. This pattern begins soon after you power
on the server. This status indicates either: power-on
self-test (POST) code checkpoint tests are running
on the server host system, or the host is transitioning
from the powered-on state to the standby state on
shutdown.
■ STEADY ON – The server is powered on, and all
host POST code checkpoint tests are complete. The
server is in one of the following states: the server
Troubleshooting and Diagnostics 29
