Oracle X7-2 Service Manual

Monitoring System Components
Cooling Unit Components
The system has four 40-mm fan modules with two fans in each module. The following table
lists the system cooling unit components.
Component Name (Oracle ILOM CLI
Targets)
IPMI Type Description Values (if applicable)
/SYS/MB/FM[0-3] FRU Fan module FRU
/SYS/MB/FM[0-3]/F[0-x] FRU Individual fan
/SYS/MB/FM[0-3]/PRSNT Discrete sensor Fan module is present. 01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
/SYS/MB/FM[0-3]/F[0-x]/TACH Threshold sensor Fan module fan speed RPM
/SYS/MB/FM[0-3]/SERVICE Indicator Fan Fault-Service Required LED Color: Amber
Location: Motherboard
Off: Normal
On: Fan module was diagnosed as
faulty.
Related Information
■
“System Chassis Components” on page 285
■
“Disk Backplane Components” on page 287
■
“Memory Device Components” on page 289
■
“Power Unit Components” on page 289
■
“Processor Components” on page 290
■
“System Motherboard Components” on page 291
■
“System Firmware Components” on page 293
■
“Hard Disk Drive Components” on page 293
Disk Backplane Components
The following table lists the disk backplane (DBP) components.
Monitoring Components and Identifying SNMP Messages 287

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
