Oracle X7-2 Service Manual

Attach Devices to the Server
Attach Devices to the Server
This procedure explains how to connect devices to the server (remotely and locally), so that you
can interact with the service processor (SP) and the server console.
1.
Connect an Ethernet cable to the Gigabit Ethernet (NET) connector as needed for
OS support.
See “Back Panel Connector Locations” on page 40.
2.
To connect to the service processor's Oracle ILOM over the network, connect an
Ethernet cable to the Ethernet port labeled NET MGT.
See “Back Panel Connector Locations” on page 40.
3.
To access the Oracle ILOM command-line interface (CLI) locally, connect a serial
null modem cable to the RJ-45 serial port labeled SER MGT.
To access the system console, connect the RJ-45 cable to a terminal or terminal emulator, log on
to Oracle ILOM, and type start /HOST/console.
See “Back Panel Connector Locations” on page 40.
Back Panel Connector Locations
The following illustration shows and describes the locations of the back panel connectors. Use
this information to set up the server, so that you can access diagnostic tools and manage the
server during service.
40 Oracle Server X7-2 Service Manual • October 2017

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
