Oracle X7-2 Service Manual

Removing and Replacing an NVMe Storage Drive Using Oracle Solaris
Removing and Replacing an NVMe Storage Drive Using
Oracle Solaris
The following sections describe how to remove and replace an NVMe storage drive on a server
that is running the Oracle Solaris operating system.
■
“Unmount an NVMe Storage Drive” on page 71
■
“Remove an NVMe Storage Drive” on page 72
■
“Verify Removal of an NVMe Storage Drive” on page 72
■
“Install an NVMe Storage Drive” on page 72
■
“Power On an NVMe Storage Drive and Attach a Device Driver” on page 73
Unmount an NVMe Storage Drive
1.
Log in to Oracle Solaris that is running on the server.
2.
To find the NVMe drive slot number, type:
# hotplug list –lc
This command produces output similar to the following for each of the NVMe drives installed
in the server:
# hotplug list –lc
Connection State Description Path
---------------------------------------------------------------------------------------
Slot100 ENABLED PCIe-Native /pci@13,0/pci8086,2030@0/pci111d,80b5@0/pci111d,80b5@5
3.
To prepare the NVMe drive for removal, that is, to detach the device driver and
power off the drive slot, type the following commands:
# hotplug poweroff Slot100
# hotplug list –lc
The following output appears for the NVMe drive that has been unmounted:
# hotplug list –lc
Connection State Description Path
---------------------------------------------------------------------------------------
Slot100 PRESENT PCIe-Native /pci@13,0/pci8086,2030@0/pci111d,80b5@0/pci111d,80b5@5
4.
Verify that the OK to Remove indicator (LED) on the NVMe storage drive is lit.
Servicing Storage Drives (CRU) 71

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
