Oracle X7-2 Service Manual

PCIe Slot Characteristics
PCIe Slot Characteristics
There are three external PCIe slots and one internal PCIe slot available in the Oracle Server
X7-2. The external slots support optional, standard PCIe cards and are numbered 1, 2, and 3
from left to right when you view the server from the rear. The internal slot, which installs on the
riser in PCIe slots 3 and 4, supports a required internal SAS controller HBA card. For a view
of the back panel that shows PCIe slot numbering, see “Back Panel Components and Cable
Connections” on page 18.
Note - PCIe slot 1 is nonfunctional in single-processor systems.
Note - All of the PCIe slots comply with the PCI Express 3.0 specification and can
accommodate 25 Watt PCIe cards.
The following table lists the characteristics and requirements of the PCIe slots.
Slot
Number
Supported PCIe Card
Types
Supported PCIe Specifications Slot Connector Width/PCI Express
Lanes
1 Low-profile cards only PCIe 1.0, PCIe 2.0, PCIe 3.0 x16 mechanical/x16 electrical
2 Low-profile cards only PCIe 1.0, PCIe 2.0, PCIe 3.0 x16 mechanical/x16 electrical
3 and 4 Low-profile cards only PCIe 1.0, PCIe 2.0, PCIe 3.0 x8 mechanical/x8 electrical
Related Information
■
“Back Panel Components and Cable Connections” on page 18
Remove a PCIe Card From PCIe Slot 1 or 2
Note - PCIe slot 1 is nonfunctional in single-processor systems.
1.
Remove the PCIe riser from the server.
See “Remove a PCIe Riser From PCIe Slot 1 or 2” on page 113.
2.
Remove the PCIe card from the PCIe riser.
122 Oracle Server X7-2 Service Manual • October 2017

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
