Assign Serial Port Output Using the Oracle ILOM Web Interface
5.
Click Save for the changes to take effect.
6.
Connect a serial host to the server.
Server Operating System Names for the NVMe
Storage Drives
If NVMe storage drives are installed in the server front panel, they are labeled NVMe0 through
NVMe7. The server operating systems assign these storage drives different names. For the
corresponding names assigned by the operating systems, see the following table.
Note - The drive names provided in the table assume that NVMe cabling between the
motherboard NVMe connectors and the disk backplane is correct.
Storage Drive Labels Names Assigned by the Server
Operating Systems
NVMe0 PCIe Slot 100
NVMe1 PCIe Slot 101
NVMe2 PCIe Slot 102
NVMe3 PCIe Slot 103
NVMe4 PCIe Slot 104
NVMe5 PCIe Slot 105
NVMe6 PCIe Slot 106
NVMe7 PCIe Slot 107
Ethernet Port Boot Order and Device Naming
This section contains information about the boot order and device naming for the Gigabit
Ethernet ports on the back panel of the server. For location information, see “Back Panel
Connector Locations” on page 40.
Ethernet Port Boot Order
The order in which the BIOS detects the Ethernet ports during server boot is listed below.
44 Oracle Server X7-2 Service Manual • October 2017

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
