Oracle X7-2 Service Manual

BIOS Advanced Menu Selections
Setup Options Options Defaults Description
Example format: Bus:Device:
Function
Link Status (R/O) NA Connected Specifies the link status of the
network port.
MAC Address (R/O) NA NA Lists the MAC address of the
network interface controller
(NIC).
Virtual MAC Address (R/O) NA NA Lists the Virtual MAC address
of the network interface
controller (NIC).
BIOS Advanced Menu Oracle Dual Port 10Gb/25Gb
SFP28 Ethernet Controller Options
The following table describes the BIOS Advanced Menu Oracle Dual Port 10Gb/25Gb SFP28
Ethernet controller options.
Setup Options Options Defaults Description
Firmware Image Menu (R/O) NA NA Lists the current firmware
versions for the Ethernet
controller.
Device Configuration Menu NA NA Configure the device.
Number of VFs per PF NA 16 Configure the number of VFs
(virtual functions) per PF
(physical functions) in multiples
of 8 (0…128).
SR-IOV Enabled/Disabled Disabled Enable/Disable single root I/O
virtualization.
Number of MSI-X Vectors per
VF
NA 16 Configure the number MSI-X
(message signaled interrupts)
Vectors per VF (0…128).
Maximum Number of PF MSI-
X Vectors
NA 255 Configure the maximum number
of PF MSI-X Vectors (0…470).
Link FEC Disabled
CL74 - Fire Code
CL91 - Reed Solomon
both CL74 and CL91
Disabled Configure Link Forward Error
Correction mode.
Energy Efficient Ethernet Enabled/Disabled Disabled Configure Energy Efficient
Ethernet operation.
262 Oracle Server X7-2 Service Manual • October 2017

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
