Oracle X7-2 Service Manual

Servicing the Motherboard (FRU)
The following section describes how to service the motherboard. The motherboard is a
field-replaceable unit (FRU). For more information about FRUs, see “Illustrated Parts
Breakdown” on page 19 and “Field-Replaceable Units” on page 22.
Caution - These procedures require that you handle components that are sensitive to
electrostatic discharge. This sensitivity can cause the components to fail. To avoid
damage, ensure that you follow antistatic practices as described in “Take Antistatic
Measures” on page 61.
Caution - Ensure that all power is removed from the server before removing or installing the
motherboard. You must disconnect the power cables before performing these procedures.
Caution - The motherboard should be removed and replaced only by authorized Oracle Service
personnel.
■
“Remove the Motherboard” on page 199
■
“Install the Motherboard” on page 205
Related Information
■
“Remove the Server From the Rack” on page 61
■
“Take Antistatic Measures” on page 61
■
“Remove the Server Top Cover” on page 62
Remove the Motherboard
Caution - Use the Oracle ILOM backup utility prior to removing the motherboard. This utility
backs up the Oracle ILOM configuration of the service processor. For more information, see the
Oracle ILOM 4.0 Documentation Library at http://www.oracle.com/goto/ilom/docs.
Servicing the Motherboard (FRU) 199

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
