Oracle X7-2 Service Manual

Servicing the Internal HBA Cables
The following section describes how to service the internal HBA cables. The HBA SAS cables
and super capacitor cable are a field-replaceable units (FRUs). For more information about
FRUs, see “Illustrated Parts Breakdown” on page 19 and “Field-Replaceable Units” on page 22.
Caution - These procedures require that you handle components that are sensitive to
electrostatic discharge. This sensitivity can cause the components to fail. To avoid
damage, ensure that you follow antistatic practices as described in “Take Antistatic
Measures” on page 61.
Caution - Ensure that all power is removed from the server before removing or installing
the HBA SAS cable assembly. You must disconnect the power cables before performing this
procedure.
Caution - The HBA SAS cable assembly should be removed and replaced only by authorized
Oracle Service personnel.
This section covers the following procedures:
■
“Remove the Internal HBA Cables” on page 179
■
“Install the Internal HBA Cables” on page 182
Related Information
■
“Extend the Server to the Maintenance Position” on page 59
■
“Take Antistatic Measures” on page 61
■
“Remove the Server Top Cover” on page 62
■
“Servicing the Internal HBA Card and HBA Super Capacitor (FRU)” on page 169
Remove the Internal HBA Cables
1.
Prepare the server for service.
Servicing the Internal HBA Cables 179

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
