Install the Power, FIM, Temperature Sensor, and Disk Backplane Data Cables
3.
Remove the temperature sensor cable.
a.
Remove the FIM from the server.
See “Remove the Temperature Sensor” on page 163.
b.
Disconnect the temperature sensor cable from the disk backplane by pulling
the cable from the connector [3].
c.
Remove the temperature sensor and cable from the FIM housing, then pull
the cable and sensor through the left-front chassis sidewall [4].
4.
Remove the FIM cable.
a.
Remove the FIM from the server.
See “Remove the Front Indicator Module” on page 157
b.
Disconnect the FIM cable from the FIM by pulling the cable from the
connector [5].
c.
Eject the FIM cable from the motherboard by opening both side latches on
the connector [6].
5.
Remove the disk backplane data cable.
a.
Eject the disk backplane data cable from the disk backplane by opening
both side latches on the connector [7].
b.
Eject the disk backplane data cable from the motherboard by opening both
side latches on the connector [8].
Related Information
■
“Install the Power, FIM, Temperature Sensor, and Disk Backplane Data
Cables” on page 196
Install the Power, FIM, Temperature Sensor, and Disk
Backplane Data Cables
1.
Install the disk backplane data cable.
196 Oracle Server X7-2 Service Manual • October 2017
