Oracle X7-2 Service Manual

Remove the Server From the Rack
■
“Remove the Server From the Rack” on page 61
■
“Reinstall the Server Into the Rack” on page 211
Remove the Server From the Rack
Caution - The server weighs approximately 35.0 lbs (15.88 kg). Two people are required to
dismount and carry the chassis.
1.
Disconnect all the cables and power cords from the server.
2.
Remove the cable management arm (CMA).
Refer to “Remove the Cable Management Arm” in Oracle Servers X7-2 and X7-2L Installation
Guide.
3.
Extend the server to the maintenance position.
See “Extend the Server to the Maintenance Position” on page 59.
4.
From the front of the server, pull the green slide-rail release tabs toward the front
of the server, and pull the server out of the rack until it is free of the rack rails.
A slide-rail release tab is located on each slide-rail.
Note - To pull the green slide-rail release tab, place your finger in the center of the tab, not on
the end, and apply pressure as you pull the tab toward the front of the server.
5.
Set the server on a sturdy work surface.
Related Information
■
“Disconnect Cables From the Server” on page 58
■
“Take Antistatic Measures” on page 61
■
“Extend the Server to the Maintenance Position” on page 59
■
“Reinstall the Server Into the Rack” on page 211
Take Antistatic Measures
1.
Prepare an antistatic surface on which to set parts during removal and
installation.
Preparing for Service 61

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
