Oracle X7-2 Service Manual

Troubleshoot Hardware Faults Using the Oracle ILOM Web Interface
Status Indicator
Name
Icon Color State and Meaning
Fan Status Amber ■ Off – The fan module is correctly installed and
operating within specification.
■ Amber – The fan module is faulty. The front TOP
FAN LED and the front and back panel Fault-Service
Required LEDs are also lit if the system detects a fan
module fault.
Storage Drive Status Indicators
There are three status indicators (LEDs) on each drive.
Status Indicator
Name
Icon Color State and Meaning
OK/Activity Green ■ OFF – Power is off or installed drive is not
recognized by the system.
■ STEADY ON – The drive is engaged and is
receiving power.
■ RANDOM BLINKING – There is disk activity.
Status indicator LED blinks on and off to indicate
activity.
Fault-Service
Required
Amber ■ OFF – The storage drive is operating normally.
■ STEADY ON – The system detected a fault with the
storage drive.
OK to Remove Blue ■ STEADY ON – The storage drive can be removed
safely during a hot-plug operation.
■ OFF – The storage drive is not prepared for removal.
Power Supply Status Indicators
There are two status indicators (LEDs) on each power supply. These indicators are visible from
the back of the server.
Status Indicator
Name
Icon Color State and Meaning
AC OK/ DC OK Green ■ OFF – No AC power is present.
■ SLOW BLINK – Normal operation. Input power
is within specification. DC output voltage is not
enabled.
Troubleshooting and Diagnostics 31

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
