Oracle X7-2 Service Manual

Troubleshooting With Diagnostic Tools
Power Issue Description Action Prevention
“Servicing Fan Modules
(CRU)” on page 81. For
instructions for installing
the server top cover, see
“Install the Server Top
Cover” on page 210.
Managing Server Hardware Faults Through the
Oracle ILOM Fault Management Shell
The Oracle ILOM Fault Management Shell enables Oracle Service personnel to view and
manage fault activity on managed servers and other types of devices.
For more information about how to use the Oracle ILOM Fault Management Shell, see the
Oracle ILOM User's Guide for System Monitoring and Diagnostics Firmware Release 4.0.x in
the Oracle Integrated Lights Out Manager (ILOM) 4.0 Documentation Library at http://www.
oracle.com/goto/ilom/docs.
Caution - The purpose of the Oracle ILOM Fault Management Shell is to help Oracle Service
personnel diagnose system problems. Customers must not launch this shell or run fault
management commands in the shell unless requested to do so by Oracle Service.
Troubleshooting With Diagnostic Tools
The server and its accompanying software and firmware contain diagnostic tools and features
that can help you isolate component problems, monitor the status of a functioning system,
and exercise one or more subsystem to disclose more subtle or intermittent hardware-related
problems.
Each diagnostic tool has its own specific strength and application. Review the tools listed in this
section and determine which tool might be best to use for your situation. After you determine
the tool to use, you can access it locally, while at the server, or remotely.
■
“Diagnostic Tools” on page 38
■
“Diagnostic Tool Documentation” on page 39
Troubleshooting and Diagnostics 37

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
