Install the Front Indicator Module
3.
Carefully slide the FIM assembly toward the front of the server to remove it from
the chassis [2].
4.
Using a Phillips screwdriver, remove the two screws that secure the plastic
temperature sensor housing to the FIM assembly, and then detach the housing
from the FIM assembly [2].
Note - You do not need to remove the temperature sensor from the housing.
5.
Disconnect the FIM cable from the FIM assembly and set the FIM assembly aside
[3].
6.
Continue to “Install the Front Indicator Module” on page 159.
Related Information
■
“Install the Front Indicator Module” on page 159
Install the Front Indicator Module
1.
Attach an antistatic wrist strap to your wrist, and then to a metal area on the
chassis.
See “Take Antistatic Measures” on page 61.
2.
Unpack the replacement FIM and place it on an antistatic mat.
Servicing the Front Indicator Module (FRU) 159
