Oracle X7-2 Service Manual

USB Ports
TABLE 8
RJ-45 to DB-9 Adapter Crossover Wiring Reference
Serial Port (RJ-45 Connector) DB-9 Adapter
Pin Signal Description Pin Signal Description
1 RTS 8 CTS
2 DTR 6 DSR
3 TXD 2 RXD
4 Signal Ground 5 Signal Ground
5 Signal Ground 5 Signal Ground
6 RXD 3 TXD
7 DSR 4 DTR
8 CTS 7 RTS
TABLE 9
RJ-45 to DB-25 Adapter Crossover Wiring Reference
Serial Port (RJ-45 Connector) DB-25 Adapter
Pin Signal Description Pin Signal Description
1 RTS 5 CTS
2 DTR 6 DSR
3 TXD 3 RXD
4 Signal Ground 7 Signal Ground
5 Signal Ground 7 Signal Ground
6 RXD 2 TXD
7 DSR 20 DTR
8 CTS 4 RTS
Related Information
■
“Back Panel Components and Cable Connections” on page 18
■
“Disconnect Cables From the Server” on page 58
■
“Reconnect Data Cables and Power Cords” on page 214
USB Ports
The server has two USB ports for attaching supported USB 3.0-compliant devices. There is one
USB port on the server back panel, and one on the motherboard.
The following figure and table describe the USB port pin signals.
Identifying the Server Ports 221

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
