Monitoring System Components
“Hard Disk Drive Components” on page 293
System Firmware Components
The following table lists the system firmware components.
Component Name (Oracle
ILOM CLI Target)
IPMI Type Description
/SYS/MB/BIOS FRU BIOS FRU
/SYS/MB/CPLD FRU Motherboard CPLD/FPGA firmware
Related Information
“System Chassis Components” on page 285
“Cooling Unit Components” on page 287
“Disk Backplane Components” on page 287
“Memory Events” on page 303
“Power Unit Components” on page 289
“Processor Components” on page 290
“System Motherboard Components” on page 291
“Hard Disk Drive Components” on page 293
Hard Disk Drive Components
The following table lists the hard disk drive (HDD) components.
Component Name (Oracle ILOM CLI
Targets)
IPMI Type Description Values (if applicable)
/SYS/DBP/HDD[0-x] FRU Hard disk drive FRU From host
/SYS/DBP/HDD[0-x]/PRSNT Discrete sensor Hard disk drive presence 01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
/SYS/DBP/HDD[0-x]/STATE Discrete sensor Writable multistate, slot/connector
sensor type, per IPMI
01h-FAULT_STATUS
02h-IDENTITY
04h-INSTALLED
Monitoring Components and Identifying SNMP Messages 293
