Oracle X7-2 Service Manual

Monitoring System Components
Component Name (Oracle ILOM CLI
Targets)
IPMI Type Description Values (if applicable)
/SYS/MB/T_OUT_SLOT[1-3] Threshold sensor Cooling zone chassis exhaust
temperature, located behind the
specified PCIe slots
■ Slot 1 – PCIe slot 1
■ Slot 2 – PCIe slot 2
■ Slot 3 – PCIe slot 3
Degrees Celsius
/SYS/MB/T_IN_SLOT[1-3] Threshold sensor Cooling zone chassis inlet
temperature, located in front of the
specified PCIe slots
■ Slot 1 – PCIe slot 1
■ Slot 2 – PCIe slot 2
■ Slot 3 – PCIe slot 3
Degrees Celsius
/SYS/SP FRU Service processor FRU
/SYS/SP/OK Indicator SP OK LED Color: Green
Location: Front panel
On: SP is operating.
Off: SP requires service.
/SYS/SP/NET[0-1] FRU SP Ethernet FRU
/SYS/MB/RISER3 FRU M.2 SSD riser
/SYS/MB/RISER3/PRSNT Discrete sensor M.2 riser presence 01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
/SYS/MB/RISER3/SSD[0-1] FRU Internal M.2 SSD drives
/SYS/MB/RISER3/SSD[0-1]/PRSNT Discrete sensor M.2 SSD drive presence 01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
/SYS/MB/RISER3/SSD[0-1]/STATE State sensor M.2 SSD drive state sensor 04h-INSTALLED
20h-SLOT_POWER_OFF
Related Information
■
“System Chassis Components” on page 285
■
“Cooling Unit Components” on page 287
■
“Disk Backplane Components” on page 287
■
“Memory Device Components” on page 289
■
“Power Unit Components” on page 289
■
“Processor Components” on page 290
■
“System Firmware Components” on page 293
292 Oracle Server X7-2 Service Manual • October 2017

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
