Oracle X7-2 Service Manual

Servicing the Front Indicator Module (FRU)
The following section describes how to service the front indicator module. The front indicator
module is a field-replaceable unit (FRU). For more information about FRUs, see “Illustrated
Parts Breakdown” on page 19 and “Field-Replaceable Units” on page 22.
Caution - These procedures require that you handle components that are sensitive to
electrostatic discharge. This sensitivity can cause the components to fail. To avoid
damage, ensure that you follow antistatic practices as described in “Take Antistatic
Measures” on page 61.
Caution - Ensure that all power is removed from the server before removing or installing
the front indicator module. You must disconnect the power cables before performing this
procedure.
Caution - The front indicator module should be removed and replaced only by authorized
Oracle Service personnel.
Follow these procedures to remove and install the front indicator module (FIM).
■
“Remove the Front Indicator Module” on page 157
■
“Install the Front Indicator Module” on page 159
Related Information
■
“Disconnect Cables From the Server” on page 58
■
“Remove the Server From the Rack” on page 61
■
“Take Antistatic Measures” on page 61
Remove the Front Indicator Module
1.
Prepare the server for service.
Servicing the Front Indicator Module (FRU) 157

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
