Oracle X7-2 Service Manual

BIOS Advanced Menu Selections
Note - Depending on the devices that are populating your PCIe slots, you will see different
entries if the devices are publishing their driver health status.
Setup Options Options Defaults Description
Intel PRO/1000 PCI-E (R/O) Healthy Lists the health status of drivers/
controllers.
Controller Child 0 (R/O) Healthy
Intel I210 Gigabit Network
Connection (R/O)
Healthy
Apache Pass Driver (R/O) Healthy Lists the health status of drivers/
controllers.
BIOS Advanced Menu Serial Port Console
Redirection Options
The following table lists the BIOS Advanced Menu Serial Console Redirection options.
Setup Options Options Defaults Description
EMS Console Redirection Disabled/Enabled Disabled Use this option to enable or
disable console redirection
for Windows Emergency
Management Service (EMS)
administration.
Console Redirection Disabled/Enabled Enabled Use this option to enable or
disable console redirection.
Terminal Type VT100/VT100+/VT-UTF8/
ANSI
VT100+ Select the emulation for the
terminal:
■ VT100: ASCII character set.
■ VT100+: Extends VT100 to
support color, function keys,
etc.
■ VT-UTF8: Uses UTF8
encoding to map Unicode
characters onto one or more
bytes.
■ ANSI: Extended ASCII
character set.
Bits per Second 9600
19200
9600 Select the serial port
transmission speed. The
speed must be matched on the
BIOS Setup Utility Menu Options 265

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
