Oracle X7-2 Service Manual

Install an NVMe Storage Drive
See “Remove a Storage Drive” on page 67.
3.
Grasp the latch and pull the drive out of the drive slot.
4.
Consider your next steps:
■
If you are replacing the drive, continue to “Install an NVMe Storage Drive” on page 79.
■
If you are not replacing the drive, install a filler panel in the empty drive slot to maintain
proper airflow and perform administrative tasks to configure the server to operate without
the drive.
For information on how to install a storage drive filler panel, see “Remove and Install Filler
Panels” on page 209.
Install an NVMe Storage Drive
Perform this procedure to physically install an NVMe storage drive into the server.
1.
Remove the replacement drive from its packaging and place the drive on an
antistatic mat.
2.
If necessary, remove the drive filler panel.
3.
Align the replacement drive with the drive slot.
The drive is physically addressed according to the slot in which it is installed. It is important to
install a replacement drive in the same slot as the drive that was removed.
4.
Slide the drive into the slot until the drive is fully seated.
See “Install a Storage Drive” on page 70.
5.
Close the drive latch to lock the drive in place.
6.
Power on the server.
See “Power On the Server” on page 214.
Verify that the power supply AC OK LED is lit.
Related Information
■
“Storage Drive Status Indicators” on page 31
■
“Storage Drives Hot-Plug Conditions” on page 65
Servicing Storage Drives (CRU) 79

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
