Oracle X7-2 Service Manual

Returning the Server to Operation
After replacing components inside of the server, perform the procedures in the following
sections:
■
“Server Filler Panel Requirements” on page 209
■
“Remove and Install Filler Panels” on page 209
■
“Install the Server Top Cover” on page 210
■
“Remove Antistatic Measures” on page 211
■
“Reinstall the Server Into the Rack” on page 211
■
“Return the Server to the Normal Rack Position” on page 212
■
“Reconnect Data Cables and Power Cords” on page 214
■
“Power On the Server” on page 214
Server Filler Panel Requirements
The server might be shipped with module-replacement filler panels for storage drives and PCIe
cards. These filler panels are installed at the factory and must remain in the server until you
replace them with a purchased option.
Before you can install an optional server component into the server, you must remove the filler
panel from the location into which you intend to install the component. When you remove
a storage drive or a PCIe card from the server, you must install either a replacement for the
component removed or a filler panel.
Remove and Install Filler Panels
See the procedures in the following table to remove and install filler panels for
storage drives and PCIe cards.
Returning the Server to Operation 209

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
