Oracle X7-2 Service Manual

Remove a Storage Drive
See “Take Antistatic Measures” on page 61.
2.
Identify the location of the drive that you want to remove.
For storage drive locations, see “Storage Drive Locations and Numbering” on page 66.
3.
Remove the storage drive.
■ If you are removing an HDD or SSD storage drive, type the operating system
commands required to stop the server from using the drive; otherwise,
proceed to the next step.
The exact commands required depend on the configuration of your drives. Unmount file
systems or issue RAID commands as needed.
Note - The blue OK to Remove status indicator LED on the drive may or may not light, as
support for this varies depending on the operating system in use. For information on storage
drive status indicators (LEDs), see “Storage Drive Status Indicators” on page 31.
■ If you are removing an NVMe storage drive, see the procedures for your
operating system.
Note - NVMe storage drives are supported only on servers that are running Oracle Solaris,
Oracle Linux, Oracle VM, or Microsoft Windows Server. Servers that are running Red Hat
Enterprise Linux do not support NVMe drives.
■
“Removing and Replacing an NVMe Storage Drive Using Oracle
Solaris” on page 71
■
“Removing and Replacing an NVMe Storage Drive Using Oracle
Linux” on page 74
■
“Removing and Replacing an NVMe Storage Drive Using Microsoft Windows
Server” on page 78
68 Oracle Server X7-2 Service Manual • October 2017

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
