About System Components
Call Out Description
13 Network (NET) 10/25GbE enhanced small form-factor pluggable (SFP+) port: NET 1
14 Network (NET) 10/25GbE SFP+ port: NET 2
15 USB 3.0 connector
16 Serial management (SER MGT) RJ-45 serial port
Note - For more information on back panel components and connections, see “Back Panel
Connector Locations” on page 40. See also “Back Panel Pinhole Switches” on page 45.
Related Information
■
“Front Panel Controls and Indicators” on page 16
■
“About System Components” on page 19
About System Components
These sections describe the components of the server:
■
“Illustrated Parts Breakdown” on page 19
■
“Customer-Replaceable Units” on page 21
■
“Field-Replaceable Units” on page 22
Illustrated Parts Breakdown
The following figure identifies the major components of the server.
