Oracle X7-2 Service Manual

BIOS Advanced Menu Selections
Setup Options Options Defaults Description
the attempt up/down in the
attempt order list.
BIOS Advanced Menu Gigabit Network
Connection Options
The following table describes the BIOS Advanced Menu Gigabit network connection options.
Setup Options Options Defaults Description
NIC configuration Use to configure the network
interface controller.
Link Speed Auto Negotiated
10 Mbs Half
10 Mbs Full
100 Mbs Half
100 Mbs Full
NA Specifies the port speed used for
the selected boot protocol.
Wake on LAN Disable/Enabled NA Use this option to enable or
disable wake on LAN.
Blink LEDs 0/1/2/3 0 Use to identify the physical
network port by blinking the
associated LED.
UEFI Driver (R/O) NA NA Identifies the UEFI driver.
Adapter PBA (R/O) NA NA Product board adapter (PBA)
number. You can use the Intel
Network Adapter PBA number
to search for the adapter's model
number. The PBA number is
a nine digit number that is the
last part of the adapter board
serial number. The PBA number
is presented in this format:
xxxxxxx-xxx, for example,
C80222-001.
Device Name (R/O) NA NA Device name.
Chip Type (R/O) NA NA Manufacturer and model
number.
PCI Device ID (R/O) NA 1533 Device identifier.
PCI Address (R/O) NA NA Bus device function identifier.
BIOS Setup Utility Menu Options 261

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
