Oracle X7-2 Service Manual

Required Tools
■
Power supply (PS), designated as a backup quorum member.
When a server FRU that contains the KIP is removed and a replacement component is installed,
the KIP of the replacement component is programmed by Oracle ILOM to contain the same
KIP as the other two components.
Note - Only one of the quorum members can be replaced at a time. Automated updates can only
be completed when two of the three quorum members contain matching key identity properties.
Related Information
■
“Servicing Power Supplies (CRU)” on page 87
■
“Servicing the Disk Backplane (FRU)” on page 151
■
“Servicing the Motherboard (FRU)” on page 199
Required Tools
The server can be serviced with the following tools:
■
Antistatic wrist strap
■
Antistatic mat
■
No. 2 Phillips screwdriver
■
Torx (6 lobe) T10, T15, T25, and T30 screwdrivers
■
12.0 in-lbs/ft (inch-pounds/foot) torque driver
Related Information
■
“Preparing for Service” on page 49
Preparing the Server for Component Replacement
Before you can remove and install components that are inside the server, you must perform the
procedures in some or all of the following tasks:
52 Oracle Server X7-2 Service Manual • October 2017

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
