DIMM and Processor Physical Layout
The physical layout of the DIMMs and processor(s) is shown in the following figure. When
viewing the server from the front, processor 0 (P0) is on the left.
Note - In single-processor systems, the DIMM sockets associated with processor 1 (P1) are
nonfunctional and should not be populated with DIMMs.
Related Information
■
“DIMM Population Scenarios” on page 99
