Oracle X7-2 Service Manual

Troubleshoot Hardware Faults Using the Oracle ILOM Web Interface
Status Indicator
Name
Icon Color State and Meaning
■ STEADY ON – Normal operation. Input AC power
and DC output voltage are within specification.
Fault-Service
Required
Amber ■ OFF – Normal operation. No service action is
required.
■ STEADY ON – The power supply (PS) detected a PS
fan failure, PS overtemperature, PS over current, or
PS over or under voltage.
Network Management Port Status Indicators
The server has one 10/100/1000BASE-T Ethernet management domain interface, labeled NET
MGT. There are two status indicators (LEDs) on this port. These indicators are visible from the
back of the server.
Status Indicator
Name
Location Color State and Meaning
Activity Top right Green ■ ON – Link up.
■ OFF – No link or down link.
■ FLASHING – Packet activity.
Link speed Top left Green ■ ON – 1000BASE-T link.
■ OFF – 10/100BASE-T link.
Ethernet Ports Status Indicators
The server has five Gigabit Ethernet (GbE) ports:
■
One 10/100/1000BASE-T RJ-45 GbE port, labeled NET 0
■
Two 10GBASE-T RJ-45 GbE ports, labeled NET 1 and NET 2
■
Two 10/25GbE enhanced small form-factor pluggable (SFP+) ports, labeled NET 1 and
NET 2
SFP+ ports support up to 10GbE when using SFP+ transceivers, and up to 25GbE when
using SFP28 transceivers.
Note - The 10/25GbE SFP+ (NET 1 and NET 2) ports are the default network ports for the
server. When using an SFP+ port, network connectivity is disabled on the 10GBASE-T RJ-45
GbE (NET 1 and NET 2) ports.
32 Oracle Server X7-2 Service Manual • October 2017

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
