Oracle X7-2 Service Manual

Servicing Other Cables
The following section describes how to service the power, front indicator module (FIM),
temperature sensor, and disk backplane data cables. These cables are field-replaceable units
(FRUs). For more information about FRUs, see “Illustrated Parts Breakdown” on page 19 and
“Field-Replaceable Units” on page 22.
Caution - These procedures require that you handle components that are sensitive to
electrostatic discharge. This sensitivity can cause the components to fail. To avoid
damage, ensure that you follow antistatic practices as described in “Take Antistatic
Measures” on page 61.
Caution - Ensure that all power is removed from the server before removing or installing these
cables. You must disconnect the power cables before performing this procedure.
Caution - The power, FIM, temperature sensor, and disk backplane data cables should be
removed and replaced only by authorized Oracle Service personnel.
This section covers the following procedures:
■
“Remove the Power, FIM, Temperature Sensor, and Disk Backplane Data
Cables” on page 194
■
“Install the Power, FIM, Temperature Sensor, and Disk Backplane Data
Cables” on page 196
Related Information
■
“Extend the Server to the Maintenance Position” on page 59
■
“Take Antistatic Measures” on page 61
■
“Remove the Server Top Cover” on page 62
Servicing Other Cables 193

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
