Oracle X7-2 Service Manual

BIOS Advanced Menu Selections
Setup Options Options Defaults Description
Add-in Video Card support Disabled/Enabled Enabled Use this option to enable or
disable video card support.
BIOS Advanced Menu Trusted Computing 2.0
Options
The following table lists the BIOS Advanced Menu Trusted Computing 2.0 options.
Note - The options in this section are available only when the Security TPM Device Support
option is set to Enabled.
Setup Options Options Defaults Description
Security TPM Device Support Disabled/Enabled Disabled Use this option to enable or
disable Trusted Platform Module
(TPM) support. If disabled, the
OS will not show TPM. Reset of
the platform is required.
Active PCR banks (R/O) N/A N/A Displays active Platform
Configuration Register (PCR)
banks.
Available PCR banks (R/O) N/A N/A Displays available Platform PCR
banks.
SHA-1 PCR Bank (R/O) N/A N/A Displays if the SHA-1 PCR bank
is enabled/disabled.
SHA256 Bank (R/O) N/A N/A Displays if the SHA256 PCR
bank is enabled/disabled.
Pending Operation None/TPM Clear None Use this option to schedule an
operation for the security device.
Note - Your computer will
reboot during restart in order to
change the state of a security
device.
Platform Hierarchy Disabled/Enabled Use this option to enable or
disable platform hierarchy.
Storage Hierarchy Disabled/Enabled Use this option to enable or
disable storage hierarchy.
Endorsement Hierarchy Disabled/Enabled Use this option to enable or
disable endorsement hierarchy.
TPM 2.0 UEFI Spec Version (R/
O)
N/A N/A Displays the TPM 2.0 UEFI
spec version.
268 Oracle Server X7-2 Service Manual • October 2017

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
