Oracle X7-2 Service Manual

Install a Storage Drive
Install a Storage Drive
1.
Remove the replacement drive from its packaging and place the drive on an
antistatic mat.
2.
If necessary, remove the drive filler panel.
3.
Align the replacement drive with the drive slot.
The drive is physically addressed according to the slot in which it is installed. It is important to
install a replacement drive in the same slot as the drive that was removed.
4.
Slide the drive into the slot until the drive is fully seated [1].
5.
Close the drive latch to lock the drive in place [2].
6.
Perform administrative tasks to reconfigure the drive.
The procedures that you perform at this point depend on how your data is configured. You
might need to partition the drive, create file systems, load data from backups, or have the drive
updated from a RAID configuration.
Related Information
■
“Storage Drive Status Indicators” on page 31
■
“Storage Drives Hot-Plug Conditions” on page 65
■
“Storage Drive Failure and RAID” on page 66
■
“Remove a Storage Drive” on page 67
70 Oracle Server X7-2 Service Manual • October 2017

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
