Oracle X7-2 Service Manual

Install the Motherboard
5.
Return the server to operation.
a.
Install the server top cover.
See “Install the Server Top Cover” on page 210.
b.
Return the server to the normal rack position.
See “Return the Server to the Normal Rack Position” on page 212.
c.
Reconnect the data cables to the server and reconnect the power cords to
the server power supplies.
See “Reconnect Data Cables and Power Cords” on page 214.
d.
Power on the server.
See “Power On the Server” on page 214.
Verify that the System OK status indicator is steady on.
Note - IMPORTANT: After replacing the motherboard, you might need to manually program
the product serial number (PSN) into the new motherboard. This is necessary because the
motherboard is a secondary member of a select group (or quorum) of components used for
maintaining the PSN for service entitlement, and if you replace more than one of the quorum
members during any given service procedure, a secondary quorum member might need to be
programmed with the PSN.
Related Information
■
“Customer-Replaceable Units” on page 21
■
“Field-Replaceable Units” on page 22
■
“Remove the Motherboard” on page 199
208 Oracle Server X7-2 Service Manual • October 2017

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
