Oracle X7-2 Service Manual

Monitoring System Components
Component Name (Oracle
ILOM CLI Targets)
IPMI Type Description Values (if applicable)
/SYS/SERVICE Indicator Fault-Service Required LED Color: Amber
Location: Front and back panels
Off: Normal
On: Server requires service.
/SYS/LOCATE Indicator Locate Button/LED Color: White
Location: Front and back panels
Off: Normal
Fast blink: Locate function is activated;
self-extinguishes after 30 minutes.
/SYS/PS_FAULT Indicator Rear Power Supply Fault LED Color: Amber
Location: Front panel
Off: Normal
On: General power supply fault
/SYS/FAN_FAULT Indicator Top Fan Fault LED Color: Amber
Location: Front panel
Off: Normal
On: General fan fault
/SYS/DO_NOT_SERVICE Indicator Do Not Service LED Color: White
Location: Front panel
Off: Normal
On: Do not service
Related Information
■
“Cooling Unit Components” on page 287
■
“Disk Backplane Components” on page 287
■
“Memory Device Components” on page 289
■
“Power Unit Components” on page 289
■
“Processor Components” on page 290
■
“System Motherboard Components” on page 291
■
“System Firmware Components” on page 293
■
“Hard Disk Drive Components” on page 293
286 Oracle Server X7-2 Service Manual • October 2017

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
