Oracle X7-2 Service Manual

Install the Internal HBA Cables
HBA Connector Disk Backplane
Connector
Storage Drives
C0 SAS 0-3 0, 1, 2, and 3
C1 SAS 4-7 4, 5, 6, and 7
4.
Install the SAS cables into the disk backplane [1, 2].
To ensure proper connections, see the SAS cable connections table in Step 3.
5.
Install the PCIe riser with the internal HBA card into PCIe slot 3 and 4.
See “Install the PCIe Riser Into PCIe Slots 3 and 4” on page 118.
6.
Return the server to operation.
a.
Install the server top cover.
See “Install the Server Top Cover” on page 210.
b.
Return the server to the normal rack position.
See “Return the Server to the Normal Rack Position” on page 212.
c.
Reconnect the data cables to the server and reconnect the power cords to
the server power supplies.
See “Reconnect Data Cables and Power Cords” on page 214.
d.
Power on the server.
See “Power On the Server” on page 214.
Verify that the System OK status indicator is steady on.
Related Information
■
“Install the Internal HBA Card and HBA Super Capacitor” on page 173
■
“Remove the Internal HBA Cables” on page 179
Servicing the Internal HBA Cables 183

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
