Setting up Compax3
192-120100 N16 C3I10T10 - December 2010
123
 Select background color:Adapt background color to personal requirements.
Functions:
 Select grid color:Adapt grid color to personal requirements.
 Memorize OSCI settings in file: The settings can be memorized in a file on any
drive. The file ending is *.OSC.
 The format corresponds to an INI file and is presented in the appendix.
 Open OSCI settings from file:Loading a memorized set of settings. The file
ending is *.OSC.
 Memorizing OSCI settings in the project:Up to four sets of OSCI settings can
be memorized in the current C3 ServoManager project. .
 Open OSCI settings from project:If settings were memorized in the project,
they can be read in again.
 Memorize OSCI measurement in file:Corresponds to memorizing the setting;
the measurement values of the measurement are stored in addition. Thus it is
possible to memorize and read measurements completely with settings. The file
ending is *.OSM.
 Export measure samples to csv file:e.g. for reading into Excel.

Parker Compax3 I10T10 Specifications

General

Rated Current	10 A
Protection Class	IP20
Supply Voltage	200-480 VAC
Control Interface	EtherCAT, CANopen
Feedback Options	Resolver
