ELECTRONIC FUEL INJECTION
4
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
4. Disconnect the fuel pump electrical harness.
5. Remove the fuel tank vent hose clamp with a suitable
plie
rs an d re move th e v ent lin e f rom t he ta nk ve nt
fitting.
6. Remove the rear seat base assembly from the vehicle
by
removing the (2) fasteners retaining the rear seat
base.
7. Remove the sh ift knob and center console from the
ve
hicle.
8. Remove the push rivets and screws retaining the RH
r
ocker panel and remove panel from the vehicle (see
Chapter 5).
9. Remove the lower bolt r
etaining the se at b elt
mechanism near the rear RH portion of the fuel tank.
Once r emoved, place the mechanism in the r ear
cargo box to keep it out of the way.
10. Remove th e ( 3) Tor x fa steners fr om th e r ear RH
fe
nder well an d re move th e fender we ll fr om the
vehicle (see chapter 5).
