4.26
ELECTRONIC FUEL INJECTION
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
11. Remove the (3) shift lever support bracket bolts and
place the bracket out of the way of the fuel tank, but
do not remove or cut the plastic wire harness retainer.
12. Remove the (2) tank bracket fasteners that retain the
fue
l tank in the chassis. Swing the tank brackets clear
of the fuel tank for removal.
13. Lift the rear of the fuel tank up first
and carefully pull
it up and out from the vehicle.
1
2
3
Do not cut
plastic strap
Set bracket by
shift lever
