Polaris 2012 RANGER RZR 570 INTL User Manual

7.21
FINAL DRIVE
7
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
5. Remove the torsion spring retainer and torsion spring
from the top of the ring gear.
6. Remove the clutch housing / ring gear and roll cage
a
ssembly from the gearcase housing.
7. Remove the RH ou tput h ub assembly fr om the
ge
arcase housing.
8. Remove pinion seal, internal retaining ring and pinion
g
ear assemb ly fro m the gea rcase ho using. Inspect
and cle an the ge arcase housing a nd r eplace all o il
seals and O-rings.
9. Inspect the pinion gear for chipped, broken or missing
te
eth. Inspect the pinion bearing for signs of wear and
the pinion shaft seal surface for pitting.
Spring Retainer
Torsion Spring
Remove as
an assembly
Internal
Pinion
Bearing
Shaft
Snap Ring
External
Snap Ring
Replace
Seal
Inspect
