7.34
FINAL DRIVE
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
18. Install an d tighte n the la rge cla mp u sing the
appropriate clamp tool.
19. While pulling out on the CV s
haft, slide a straight O-
ring pick or a small slotted screw driver between the
small end of the boot and the shaft. This will allow the
air pressure to equalize in the CV boot in the position
that the joint will spend mos t of its life. Before you
remove your instrument, be sure the small end of the
boot is in its correct location on the shaft.
20. Install and tighten the small clamp on the boot using
th
e appropriate clamp tool.
Axle Boot Clamp Tool: PU-48951
or
CV Boot Clamp Pliers: 8700226
Axle Boot Clamp Tool: PU-48951
or
CV Boot Clamp Pliers: 8700226
