4. By hand, install the (8) engine to transmission coupler
brackets, bolts and washers. Do not torque fasteners
at this time.
5. Install th e Clutch Center Dista nce Tool (PU-50658)
o
nto th e cr ankshaft an d tr ansmission input shaft to
properly position the clu tch ce nter distance. The
pictures below sho w the too l ( PU-50658) p roperly
installed.
6. Torque the rear tran smission m ount fasteners to
specification.
7. In se quence, torq ue th e ( 8) e ngine cou pler br acket
fa
steners to specification.
8. Remove the clutch center distance tool.
9. Remove the s pacer or support between th e vehicle
fra
me and engine.
Drive Clutch Bolt Installed
Rear Engine Coupler Fastener Torque:
(In Sequence)
55 ft. lbs. (74.5 Nm)
25 ft. lbs.
(34 Nm)
40 ft. lbs.
(54 Nm)
20 ft. lbs.
(27 Nm)
