8.16
TRANSMISSION
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
Snorkel Shaft Removal / Disassembly
25. Extract the seal from the snorkel shaft to access
the
snorkel tube for removal.
26. Using the Snorkel Tool (PA-50231), fully loosen the
snorkel tube.
27. Remove the snorkel tube and shaft assembly from the
t
ransmission case.
28. Remove the sna p rin g (Y) and shim ( Z) fro m th e
sn
orkel shaft.
29. Use an arbor press to remove the snorkel tube from
th
e snorkel shaft.
30. Remove the snap ring (A) and shim (B) retaining the
bea
ring in the snorkel tube.
CAUTION
The pinion shaft must be removed prior to removing
the snorkel shaft assembly. Failure to remove pinion
shaft, will result in damage to the snorkel shaft.
Seal Removed
PA-50231
YZ
B
A
