TRANSMISSION
8
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
21. Install the tra nsmission d rain plu g an d torq ue to
specification.
22. Install the bellcrank onto the shift
shaft. Note the key
splined on the bellcrank and shift shaft. Install the nut
and torque to specification.
23. Refer to “Transmission Installation” to complete the
r
epair.
= T
Fill / Drain Plug:
10-14 ft. lbs. (14-19 Nm)
= T
Bellcrank Nut:
12-18 ft. lbs. (16-24 Nm)
