Link Z Links the associated speaker in all the height layers Tl +L + Bl etc.
Link L Links the associated speakers that are on the same Z layer.
LFE Includes the LFE Speaker(s) in the Link Group.
Mute Clicking on a speaker mutes it. Selections are cumulative.
Solo Clicking on a speaker solos it. Selections are cumulative.
C Works in conjunction with Solo and SoloX. Toggles between In Place and Center.
Center routes the soloed channel(s) to the Center speaker or equally to the L/R
speakers if no center speaker is present. In Place mode is the normal Solo, SoloX
mode.
SoloX Solo eXclusive on the clicked speaker. Selections toggle.
Phase Toggles the phase of the selected speaker(s). Useful for quick image checks.
RS Reset. Deselect all speakers.
Output, right-hand area
Monitor Level box Displays the current output level. Output level can be entered numerically in the box after
clicking on it.
Volume Knob: sets all the output gains in a range from -144.5dB to +24dB. Double-click to set it to 0dB.
Note: Maximum permissible volume can be set in the Configure page.
Mute: button mute the outputs.
Dim: button reduces the output level by an amount set in the Configure page. Default value is -20dB.
