Monitor : Configure page
11 - 317
Configure page
The Configure page enables multiple Speaker Sets, each with multiple down-mixes, to be created and edited.
Nine factory Speaker Sets (On the left of the page, labelled on a red background at the top of the Speaker Sets
list) are installed with Pyramix. Their Main channel to speaker Main Grid and Down-Mix assignments cannot be
changed, but their output Patches from speakers in the Monitor to physical outputs can.
Speaker Types
The following Channel/Speaker Types are available:
None (Channel Type only. Used for Buses and Media with no Type assigned.)
LLeft
CCenter
RRight
Ls Left Surround
Rs Right Surround
LFE Low Frequency Effects
Lc Left Center
Rc Right Center
Cs Centre Surround
Sl Side Left
Sr Side Right
Lcs Left Surround Center
Rcs Right Surround center
VoG Voice of God
Tl Top Left
Tc Top Center
Tr Top Right
Trl Top Surround Left
Trc Top Surround Center
Trr Top Surround Right
Tsl Top Side Left
Tsr Top Side Right
Bl Bottom Left
Bc Bottom Centre
Br Bottom Right
Brl Bottom Surround Left
Brc Bottom Surround Center
Brr Bottom Surround Right
Bsl Bottom Side Left
Bsr Bottom Side Right
VOD Voice of Devil
LFE2 Low Frequency Effects 2
Factory Speaker Sets
Stereo
Near
5.1 Surround
