GPI / GPO Control : GPI / GPO Support
25 - 592
Control of the Record Red light.
Out 4 : Mixer | 1 (Strip 1 - Mono) | Gain Bus 1 | Gain
Fader start of the first mixer fader. For dB value the threshold is -90 dB
Out 5 : Mixer | 2 (Strip 2 - Mono) | Gain Bus 1 | Gain
Fader start of the second mixer fader. For dB value the threshold is -90 dB
Out 6 : Mixer | Mute Bus 1 | Reset Solo
Control of an additional indicator in the mixer room when a mixer strip is soloed.
GPI/O Remote types
There are 5 different types of Remote that can be used with GPI/O Input and/or Output pin:
• Toggle can be associated with both input and output pins.
• Range can be associated with both input and output pins and acts like a toggle 0 =off, other = on
• Event can only be associated with input pins.
• Event-Status can be associated with input and/or output pins;
• Status can be only associated with output pins.
The other Remotes cannot be mapped to GPI/O pins.
GPI/O Input and Output Pin Configuration
• Input pins mapped to Toggle or Range remotes can be configured as:
• Normal Input
•Inverted Input
• Rising Event
• Falling Event
Input pins mapped to Event or Event-Status remotes can be configured as:
• Rising Event
• Falling Event
Output pins mapped to Toggle or Range remotes can be configured as:
• Normal Status
• Inverted Status
Output pins mapped to Status or Event-Status remotes can be configured as:
• Normal Status
• Inverted Status
