Settings : Video
29 - 770
HH:MM:SS The drop-down list offers the following choice of TimeCode display formats:
HH:MM:SS
HH:MM:SS:FF
S :HH:MM:SS
S : HH:MM:SS:FF
(D) HH:MM:SS
(D)HH:MM:SS:FF
MM:SS:FF
Bottom Left The drop-down list offers the following choice of TimeCode display positions:
top left
top centre
top right
centre left
centre
centre right
bottom left
bottom centre
bottom right
MS Shell Dlg2 Clicking in the field opens a Select Font dialog with a choice of Font, Font style
and size.
Text Color Clicking in the field opens a color picker where the Text Color may be selected.
Size (% Of display) The percentage may be typed directly, set with the increment/decrement buttons
or with the mouse scroll wheel when the cursor is over the field.
Name
When checked a Name is overlayed on the Video Output according to the parameters set here.
Clip Name The drop-down list offers the choice of:
Track Name
Clip Name
Media Name
MS Shell Dlg2 Clicking in the field opens a Select Font dialog with a choice of Font, Font style
and size.
Text Color Clicking in the field opens a color picker where the Text Color may be selected.
Bck Color (Background color) Clicking in the field opens a color picker where the Background Color may be
selected.
Size (% Of display) The percentage may be typed directly, set with the increment/decrement buttons
or with the mouse scroll wheel when the cursor is over the field.
Delay compensation
Use Delay Compensation when the Video output is delayed with respect to the Audio
Graphics delay Compensates for the graphic card(s) output delay.(computer screen) Type a value
(in frames) or use the increment / decrement buttons.
Video delay Compensates for the video card(s) output(s) (Blackmagic Design). Type a value (in
frames) or use the increment / decrement buttons.
Note: These are global user settings.
