Scalar i2000 Installation Guide 271
8 For each of the six screws on the top cover of the access door:
a. Place the disposable screw capture tool over the screw.
b. Insert the #2 Phillips screwdriver through the disposable screw capture tool until seated on the
screw.
c. Remove the screw and set it aside.
Be careful when removing the last screw that the skin does not fall off the front
of the access door.
six #2 Phillips screws
top cover on
access door
