Scalar i2000 Installation Guide 285

15 Route the W6 cable from the LBX board following the door interlock cable to the front of the expansion

module, allowing the W6 cable to hang near where the I/E station lock assembly will be located.

W6 I/E station cabling

I/E W6 cable and

LBX board
