Scalar i2000 Installation Guide 293
46 After inserting the screws, tighten the screws to ensure the bottom edge of the shroud is flat against the
cross bar of the door opening. Make certain there is no gap.
47 Repeat Step 40 through Step 45 to install the second I/E station.
Make certain bottom edge of
shroud is flat against the cross
bar and there is NO gap
